U-PROX IP402
Price coming soon
2-year manufacturer’s warranty.
Sold to business customers only.
Cloud-based single-door access controller with a touch-free exit button, Ethernet and Wi-Fi.
U-PROX IP402 is a cloud-based access controller for a single one-way access point. The controller has a built-in touch-free exit button that activates at 2–5 cm distance, and connects to the network with Ethernet or Wi-Fi. It is set up from the phone with the U-PROX Config app via Bluetooth, and can be run with U-PROX ACS Cloud or locally with U-PROX WEB. A reader is connected via OSDP 2.2 or RS-232. A power supply is not included.
Key features
- Controls 1 access point (1 door, one-way, 1 reader)
- Built-in touch-free exit button (RTE), activates at 2–5 cm distance
- Ethernet 100 Mbit and Wi-Fi 2.4 GHz (802.11 b/g/n)
- Set-up and configuration from the phone via Bluetooth (U-PROX Config app)
- Operation with U-PROX ACS Cloud or locally with U-PROX WEB
- Cloud-based firmware update
- Reader via OSDP 2.2 (RS-485): U-PROX SE or other readers with OSDP 2.2 support
- Reader via RS-232: U-PROX readers only
- Solid-state lock relay (NO/COM, 1 A @ 30 V) with inversion mode
- Inputs for door contact (DC), exit button (RTE) and tamper contact; alarm output (open collector)
- Local storage for up to 10,000 identifiers and 20,000 events
- Supports schedules, time zones and holidays
- The reader ports are protected against short circuit, overvoltage and reverse polarity
Technical specifications
- Doors: 1 (one-way, 1 reader)
- Reader interface: OSDP 2.2 (RS-485), up to 1,000 m, or RS-232 (U-PROX readers only), up to 10 m
- Inputs: door contact (DC), exit button (RTE), tamper contact
- Built-in touch-free exit button: activates at 2–5 cm distance
- Relay output: 1 × solid-state relay (NO/COM, 1 A @ 30 V), inversion mode
- Alarm output (OUT): open collector, 12 V
- Network: Ethernet 100 Mbit (802.3 100BaseT), Wi-Fi 2.4 GHz (802.11 b/g/n), Bluetooth for set-up
- Identifiers: 10,000
- Event log: 20,000
- Weekly schedules: 250, time zones: 250, holidays: 250
- Temporary identifiers: 1,000
- Real-time clock and non-volatile memory
- Power supply: external 12 V (+10.8…15 VDC), consumption <120 mA @ 12 V with no load. A power supply is not included
- Temperature range: –10°C to +55°C
- Dimensions: 84.3 × 84.3 × 14.5 mm
- Weight: 0.18 kg
- Enclosure: ABS+PC plastic and Gorilla Glass, black
- Supplied with: controller, mounting kit and quick-start guide
